A. ALARM LIST
309
Number ContentsMessage
5018 POLYGON AXIS SPPED ERROR
(T series)
The rotating speed ratio of the command value cannot be maintained
in the G51.2 mode , because the spped of the spindle or the polygon
turning synchronous axis exceeds the clamp value or itis too slow.
5020 PARAMETER OF RESTART
ERROR
An erroneous parameter was specified for restarting a program.
A parameter for program restart is invalid.
5059 RADIUS IS OUT OF RANGE
(T series)
During circular interpolation, the center of the arc specified with I, J,
and K caused the radius to exceed nine digits.
5073 NO DECIMAL POINT A decimal point is not specified for a command for which a decimal
point must be specified.
5074 ADDRESS DUPLICATION ERROR The same address has been specified two or more times in a single
block. Alternatively, two or more G codes in the same group have been
specified in a single block.
5110 IMPROPER G–CODE
(G05.1 G1 MODE)
(M series)
An illegal G code was specified in look–ahead control mode (multi
blocks are read in advance).
A command was specified for the index table indexing axis in look–
ahead control mode (multi blocks are read in advance).
5111 IMPROPER MODAL G–CODE
(G05.1 G1)
(M series)
An illegal G code is left modal when look–ahead control mode was spe-
cified.
5112 G08 CAN NOT BE COMMANDED
(G05.1 G1)
(M series)
Look–ahead control (G08) was specified in look–ahead control mode
(multi blocks are read in advance).
5113 CAN NOT ERROR IN MDI MODE
(G05.1)
(M series)
Look–ahead control (multi blocks are read in advance) (G05.1) was
specified in MDI mode.
5114 NOT STOP POSITION
(G05.1 Q1)
(M series)
At the time of restart after manual intervention, the coordinates at which
the manual intervention occurred have not been restored.
5156 ILLEGAL AXIS OPERATION
(M series)
In look–ahead control mode (multi blocks are read in advance), the con-
trolled axis selection signal (PMC axis control) changes.
In look–achead control mode (multi blocks are read in advance), the
simple synchronous axis selection signal changes.
5157 PARAMETER ZERO
(M series)
Zero is set in the parameter for the maximum cutting feedrate (parame-
ter No. 1422 or 1432).
Zero is set in the parameter for the acceleration/deceleration before in-
terpolation (parameter No. 1770 or 1771).
Set the parameter correctly.
5195 DIRECTION CAN NOT BE JUDGED
(T series)
When the touch sensor with a single contact signal input is used in the
direct input B function for tool offset measurement values, the stored
pulse direction is not constant. One of the following conditions exists:
· The stop state exists in offset write mode.
· Servo off state
· The direction varies.
· Movement takes place simultaneously along two axes.
5257 G41/G42 NOT ALLOWED IN MDI
MODE
G41/G42 (cutter compensation C: M series, tool–nose radius com-
pensation: T series) was specified in MDI mode. (Depending on the set-
ting of bit 4 of parameter No. 5008)
