7.TROUBLESHOOTING

251

*JV7G0010

*JV6

*JV5

*JV4

+JV3

*JV2

*JV1

*JV0

↓↓ ↓

*JV15G0011 *JV14 *JV13 *JV12 +JV11 *JV10 *JV9 *JV8

When override value is 0%, all bits of the above address is

[1111 1111] or [0000 0000].. . . . . .

*JV15 JV0. . . . . . . . . . . . . . Override

1111 1111 1111 1111

1111 1111 1111 1110

1101 1000 1110 1111

0000 0000 0000 0001

0000 0000 0000 0000

0.00%

0.01%

100.00%

655.34%

0.00%

In this case, the CNC’s status display shows RESET. Refer to item 1.

(2)Only rapid traverse in positioning (G00) does not function Confirm

the following parameter and signals from the PMC.

(a) Setting value of rapid traverse rate

1420 Rapid traverse rate per axis

(b)Rapid traverse override signals

G0014

#6 #5 #4 #3 #2 #1

ROV2

ROV1

HROVG0096

*HROV6 *HROV5 *HROV4 *HROV3 *HROV2 *HROV1 *HROV0

(HROV–0) (HROV=1)

ROV1 ROV2 Override

100%

50%

25%

*HROV6 *HROV0 Override

1111111

1111110

0011011

100%

1421 Rapid traverse override F0 rate

(3)Only feed (other than G00) does not function

(a) Maximum feedrate set by parameter is incorrect.

1422 Maximum feedrate

Feedrate is clamped at this upper feedrate.

(b)Feedrate is specified by feed per revolution (mm/rev)

1) Position coder does not rotate

Check the connection between spindle and position coder

The following failure is considered:

D Timing belt is broken

D Key is removed

D Coupling is loose

D Connector of signal cable is loosened

2) Position coder is faulty

i. NC is in a reset state
