Series 0i - Model A Maintenance manual Page 191

Maintenance manual

Page of 402

/ 402

B–63505EN/02

4.INTERFACE BETWEEN NC AND PMC

173

MODE INPUT/OUTPUT SIGNAL FEED RATE,

ETC

EDIT [PMC ⇒ CNC]

KEY3(Program protect key)

MEM

MDI

RMT

[PMC ⇒ CNC)

ST (Cycle start)

*SP (Feed hold)

SBK (Single block)

DRN (Dry run)

BDT1∼9 (Block delete)

MIα (Mirror image)

STLK (Start lock:T)

CDZ (Chamfering:T)

SMZ (In–position check:T)

PN1∼8 (External program no. search)

MINP (External program input)

DNCI (DNC input mode)

HSα1A∼D(Handle interrupt axis select)

AFL (Auxiliary function neglect)

FIN, MFIN2, MFIN3

(Auxiliary function complete)

MFIN, SFIN, TFIN, TFIN

(High speed M/S/T function com-

plete)

GR1, 2 (Gear input T)

*SSTP (Spindle stop)

SAR (Spindle speed arrival)

SOR (Spindle orientation)

[PMC ⇒ CNC]

*FV0∼7

(Feed rate over-

ride)

OVC

(Override can-

cel)

ROV1,ROV2,

HROV,

*HROV0∼6

(Rapid traverse

override)

SOV0∼7

(Spindle speed

override)

[CNC ⇒ PMC]

STL (Cycle start LED)

SPL (Feed hold LED)

MF, M00∼M31

MF2, M200∼M215 (Miscellaneous

function)

MF3, M300∼M315

SF, S00∼S31 (Spindle speed function)

TF, T00∼T31 (Tool function)

BF, B00∼B31 (2nd miscellaneous func.)

DEN (Distribution end)

OP (automatic operating)

GR1O∼GR3O(Gear selection:M)

4.4

LIST OF SIGNALS BY

EACH MODE

D Automatic operation
