1. DISPLAY AND OPERATION

B–63505EN/02

Clear

Function

Data

prote-

ction

key

Param-

eter

write=1

Mode

Func-

tion

key

Operation

Memory all clear At

power

AND

RESET DELETE

Parameter/offset

clear

Power

RESET

Clearing a program

Power

DELETE

Program under

edition at power

off(PS101)

– ANDPROG

RESET

PMC nonvolatile

memory

Power

AND

* PMC ladder program is not cleard in FROM.

Manual operation

Function

KEY

PWE

Mode

Func-

tion key

Operation

Manual refer-

ence point

return

JOG

Turn on Reference point return switch ³ Turn on +X, –X, +Z, or –Z ³

Reference point return switch LED lit.

Jog feed JOG

Turn on +X, –X, +Z, or –Z ³ Use JOG FEEDRATE to set jog feedrate

³ Press Rapid traverse button, if required.

Incremental

feed

INC

Use Move distance selection switch to select move distance ³ Turn on

+X, –X, +Z, or –Z ³ Press Rapid traverse button, if required.

Manual

handle feed

HND

Use Axis selection switch to select axis to be operated ³ Use Handle

magnification selection to select magnification ³ Turn manual pulse

generator.
