1. DISPLAY AND OPERATION

B–63505EN/02

202

CSA

BLA

PHA

RCA

BZA

CKA

SPH

DGN

#6(CSA): Hardware of serial pulse coder is abnormal

#5(BLA): Battery voltage is low (warning)

#4(PHA): Serial pulse coder or feedback cable is erroneous.

#3(RCA): Serial pulse coder is faulty.

Counting of feedback cable is erroneous.

#2(BZA): Battery voltage became 0.

Replace the battery and set the reference position.

#1(CKA): Serial pulse coder is faulty.

Internal block stopped.

#0(SPH): Serial pulse coder or feedback cable is faulty.

Counting of feedback cable is erroneous.

DTE203

CRC

STB

PRM

#3 #2 #1 #0

DGN

#7(DTE): Communication failure of serial pulse coder.

There is no response for communication.

#6(CRC): Communication failure of serial pulse coder.

Transferred data is erroneous.

#5(STB): Communication failure of serial pulse coder.

Transferred data is erroneous.

#4(PRM): The alarm is detected by the servo, the values specified in the parameter is

not correct.

204

OFS

MCC

LDA

PMS

#2 #1 #0

DGN

#6(OFS): Abnormal current value result of A/D conversion of digital

#5(MCC): Contacts of MCC of servo amplifier is melted.

#4(LDA): Serial pulse coder LED is abnormal

#3(PMS): Feedback is not correct due to faulty feedback cable.

OHA205

LDA

BLA

PHA

CMA

BZA

PMA

SPH

DGN

#7(OHA): Overheat occurred in the stand–alone type pulse coder.

#6(LDA): An LED error occurred in the stand–alone type pulse coder.

#5(BLA): A low battery voltage occurred in the stand–alone type pulse coder.

#4(PHA): A phase data error occurred in the stand–alone type linear scale.

#3(CMA): A count error occurred in the stand–alone type pulse coder.

D Details of stand–alone

type serial pulse coder

alarms
