Series 0i - Model A Maintenance manual Page 189

Maintenance manual
B–63505EN/02
4.INTERFACE BETWEEN NC AND PMC
171
1 Data table setting screen
PMC DATA TBL CONTROL #001
G.DATA
G.CONT NO.SRH
MONIT RUN
INIT
No. of screen
NO. ADDRESS PARAMETER TYPE NO.OF DATA
001 D0000 00000000 0 10
002 D0020 00000011 1 20
003
004
005
006
007
008
No. of
data table
groups
No. of
data table
GROUP TABLE COUNT = 2
Group no. of
data table
Data table
head ad-
dress
Data length
Table
parameter
a. Soft key [G.DATA] : Select data display screen of data table.
(Next screen)
b.
NO. OF GROUPS [G.CONT]: Set the no. of groups of data table.
c.
Group No. [NO.SRH]: Move the cursor to a specified group.
d. Soft key [INIT]: Initializes the setting of data table.
No. of groups is 1, ADDRESS is D0000, PARAMETER is 0000000,
TYPE is 0, NO. OF DATA is 1860.
This operation is done usually when a sequence program is prepared.
When PMC parameters are set, internal parameters are not affected.
PARAMETER
#7
K019
#6 #5 #4 #3 #2 #1 #0
0 : Binary format
1 : BCD format
0 : Without protection for input
1 : With protection for input
TYPE
0 : 1–byte length 1 : 2–byte length 2 : 4–byte length
e. Using the page key
PAGE
/
PAGE
, next screen/previous screen can be
selected.
(The screen cannot be switched when the field indicating the number
of screens is blank.)
D DATA TABLE screen
Previous page
Next page
