Series 0i - Model A Maintenance manual Page 150

Maintenance manual
3. INPUT AND OUTPUT OF DATA
B–63505EN/02
132
7)
0103 Baud rate
1: 50 5: 200 9: 2400
2: 100 6: 300 l10: 4800
3: 110 7: 600 11: 9600
4: 150 8: 1200 12: 19200 [BPS]
3. Press soft key
4. Press soft key [READ] and [EXEC]. Then input of parameters are
started.
5. After parameters have been inputted, turn off power and turn it on.
6. Alarm 300 is issued if the system employs an absolute pulse coder.
In such a case, perform reference position return again.
Set the emergency stop state.
Operation of 12 is not required when PPR is used.
1. Turn off (KEY4=1) the program protect key.
2. Press
OFFSET
SETTING
key and soft key [SETTING] to select the SETTING
screen.
3. Confirm that PARAMETER WRITE=1.
4. Press
SYSTEM
key and soft key [PMC].
5. Press soft key [PMCPRM] and soft key [KEEPRL].
6. Set the cursor to K17 and set bit 1 to 1.
0 0 0 0 0 0
1
0
INPUT
.
7. Press
key and key.
8. Press soft key [I/O] and set the parameters required for I/O.
Item selection cursor displays the next item after an item is set.
9. In CHANNEL item , press
1
INPUT
to select channel 1.
10.In DEVICE item, press [FDCAS] key to select the floppy cassette.
11. In FUNCTION item, press soft key [READ] to input data
12.In FILE NO item, press
2
INPUT
to select file no. 2.
13.Press soft key [EXEC] and the PMC parameters are started to be input.
14.After data has been read, turn off power and turn it on.
3.2.9
Inputting PMC
Parameters
Previous page
Next page
