Series 15i/150i - Model B Maintenance manual Page 259

Maintenance manual
B–63785EN/01
3. DATA INPUT/OUTPUT
237
(5)Click the [(PROG#)] soft key.
(6)Key in the program number.
(7)Click the [EXEC] soft key.
Method 2
(1)Click the [PUNCH] soft key.
(2)Click the [”FILE NAME] soft key.
(3)Key in the file name.
(4)Click the [FILE NAME”] soft key.
(5)Click the
O
address key.
(6)Key in the program number.
(7)Click the [EXEC] soft key.
Method 1
(1)Click the [PUNCH] soft key.
(2)Click the [(FILE#)] soft key.
(3)Key in the file number.
(4)Click the [(PROG#)] soft key.
(5)Key in the program number.
(6)Click the [EXEC] soft key.
Method 2
(1)Click the [PUNCH] soft key.
(2)Click the
N
address key.
(3)Key in the file name.
(4)Click the
O
address key.
(5)Key in the program number.
(6)Click the [EXEC] soft key.
Method 3
(1)Click the
N
address key.
(2)Key in the file number.
(3)Click the
O
address key.
(4)Key in the program number.
(5)Click the [PUNCH] soft key.
Method 1
(1)Click the [PUNCH] soft key.
(2)Click the [(PROG#)] soft key.
(3)Key in the number of the first program to be output.
(4)Click the [,(PROG#)] soft key.
(5)Key in the number of the last program to be output.
(6)Click the [EXEC] soft key.
D Methods in which the file
number is specified
Outputting specified
multiple programs
D Methods in which neither
the output file name nor
number need be
specified
