1. SCREEN INDICATIONS AND OPERATIONS
B–63785EN/01
76
Example) To register “αTABLE”
FANUC code : *6641*TABLE
JIS code : *2641*TABLE
NOTE
The following characters cannot be used in an item
name: *, [, ], (, ), and ;.
(1) Position the cursor to the life to be set using the
cursor keys.
(2) Key in the time. Set a value of between 0 and 999999 (hours).
(3) Press soft key [INPUT] or the
INPUT
key.
The same value is set for both the life and remaining time, and the
count type is initialized.
(4) When the time is keyed in and soft key [+INPUT] is pressed, the time
is added to the previously set life. The time is also added to the
remaining time.
NOTE
When no item name is set, the life is not set.
(1) Position the cursor to the remaining time to be set using the
cursor keys.
(2) Key in the time. Set a value between 0 and 999999 (hours).
(3) Press soft key [INPUT] or the
INPUT
key.
(4) When the time is keyed in and soft key [+INPUT] is pressed, the time
is added to the previously set remaining time.
NOTE
When no item name is set, the remaining time is not set.
(1) Position the cursor to the count type to be set using the
cursor keys.
(2) Press soft key [NO COUNT], [ALL TIME], [POWER ON], [AUTO
START], or [CUTTING] to select the count type.
Setting the life
Setting the remaining
time
Setting the count type
