Series 15i/150i - Model B Maintenance manual Page 275

Maintenance manual
B–63785EN/01
3. DATA INPUT/OUTPUT
253
Method 1 (neither the output file name nor number need be specified)
(1)Click the [PUNCH] soft key.
(2)Click the [PERIODMAINTE] soft key.
Method 2 (the output file name is specified)
(1)Click the [PUNCH] soft key.
(2)Click the [”FILE NAME] soft key.
(3)Key in the file name.
(4)Click the [FILE NAME”] soft key.
(5)Click the [PERIODMAINTE] soft key.
Method 3 (the file number is specified, one of three methods)
(1)Click the [PUNCH] soft key.
(2)Click the [(FILE#)] soft key.
(3)Key in the file number.
(4)Click the [PERIODMAINTE] soft key.
Method 4 (the file number is specified, one of three methods)
(1)Click the [PUNCH] soft key.
(2)Click the
N
address key.
(3)Key in the file number.
(4)Click the [PERIODMAINTE] soft key.
Method 5 (the file number is specified, one of three methods)
(1)Click the
N
address key.
(2)Key in the file number.
(3)Click the [PUNCH] soft key.
NOTE
When method 1 (in which neither the output file name nor
number need be specified), described in “Output of item
selection menu (machine system) data,” is used to output
item selection menu (machine system) data to a FANUC
Handy File and Memory card, the file name will be
PMNTMCN.TXT.
Executing output
