B-63844EN/02 MANUAL GUIDE 0i 1.MANUAL GUIDE 0i

- 775 -

1.7 ALARMS

If one or more of the set of the parameters or inputted programs are

not correct when an attempt is made to execute that program, the

following P/S alarms are raised.

When an alarm other than the following P/S alarms is raised, refer to

the relevant NC operator’s manual.

Alarm Description

Cause Necessary data is not entered. Or entered data is invalid.

Action Display the block data of pop-up window, at which is occurred the alarm, and

enter the correct data after confirming it.

3001

Reference 1.4.2 Data for Each Canned Cycle

All cycle machining except for hole machining

Cause The offset data corresponding to the specified D code is 0 or less.

Action Confirm the D code, at which is occurred the alarm and enter the correct data to

the offset table.

3002

Reference 1.4.2 Data for Each Canned Cycle

All cycle machining except for hole machining

Cause Machining is impossible because the cutter diameter is too large.

Action Confirm the tool or block data, at which is occurred the alarm and select the tool

of smaller radius than the last time.

3004

Reference 1.4.2 Data for Each Canned Cycle

Pocketing

Cause The tool interferes with the opposite edge because the length of approach is too

long.

Action Confirm the approach data, at which is occurred the alarm and enter the correct

data to the approach.

3005

Reference 1.4.2 Data for Each Canned Cycle

Pocketing

Cause Corner R interferes with the opposite one because the radius of corner R is too

large.

Action Confirm the radius of corner R, at which is occurred the alarm and enter the

correct data to the radius.

3006

Reference 1.4.2 Data for Each Canned Cycle

Pocketing in the cased of Corner R

Cause Corner R machining can not be performed because the cutter diameter is larger

than corner R.

Action Confirm the tool or block data, at which is occurred the alarm and select the tool

of smaller radius than the last time.

3008

Reference 1.4.2 Data for Each Canned Cycle

Pocketing in the cased of Corner R

Cause The chamfering tool interferes with the bottom surface (Z point) in chamfering.

Action Confirm the block data or block data related to chamfer tool, at which is

occurred the alarm and enter the correct data to it.

3012

Reference 1.4.2 Data for Each Canned Cycle

Pocketing

Cause The angle at which the chamfering tool is placed is not specified.

Action Confirm the block data related to chamfer tool, at which is occurred the alarm

and enter the correct data to it.

3013

Reference 1.4.2 Data for Each Canned Cycle

Chamfering in Pocketing
