OPEN CNC (Machining Status Monitoring Package) Operators manual Page 178

Operators manual
6. MONITORING CNC MACHINES AND OUTPUTTING LOG DATA B-63364EN/03
- 162 -
6.4.1 Notes on Outputting Log Data
NOTE
Do not edit the log data output file during log data output.
If the user wishes to edit the log data output file, stop the
monitoring of all CNC machines, open the log data output file
using a program such as MS Excel independently of the
Machining Status Monitor Package, and edit it.
If MS Excel is in the input wait state during the execution of monitoring or
the output of log data, the monitoring of all CNC machines or the output of
log data is halted.
Do not leave MS Excel in any of the following states for an extended
period:
• A cell is awaiting input.
• The screen for setting the cell display format, "Format Cells," is
displayed.
• The screen whose title is "Microsoft Excel" (for example, the
following worksheet delete screen) is displayed.
