PROGRAMMING15. CUSTOM MACRO

B–63614EN/01

296

Workpiece zero point offset values can be read and written.

Table 15.2 (l) System variables for workpiece zero point offset values

Variable

number

Function

#5201

#5204

First–axis external workpiece zero point offset value

Fourth–axis external workpiece zero point offset value

#5221

#5224

First–axis G54 workpiece zero point offset value

Fourth–axis G54 workpiece zero point offset value

#5241

#5244

First–axis G55 workpiece zero point offset value

Fourth–axis G55 workpiece zero point offset value

#5261

#5264

First–axis G56 workpiece zero point offset value

Fourth–axis G56 workpiece zero point offset value

#5281

#5284

First–axis G57 workpiece zero point offset value

Fourth–axis G57 workpiece zero point offset value

#5301

#5304

First–axis G58 workpiece zero point offset value

Fourth–axis G58 workpiece zero point offset value

#5321

#5324

First–axis G59 workpiece zero point offset value

Fourth–axis G59 workpiece zero point offset value

#7001

#7004

First–axis workpiece zero point offset value (G54.1 P1)

Fourth–axis workpiece zero point offset value

#7021

#7024

First–axis workpiece zero point offset value (G54.1 P2)

Fourth–axis workpiece zero point offset value

: :

#7941

#7944

First–axis workpiece zero point offset value (G54.1 P48)

Fourth–axis workpiece zero point offset value

D Workpiece coordinate

system compensation

values (workpiece zero

point offset values)
