OPERATION8. DATA INPUT/OUTPUT

B–63614EN/01

570

CNC memory data that has been saved to a memory card can be loaded

(restored) back into CNC memory.

CNC memory data can be loaded in either of two ways. In the first

method, all saved memory data is loaded. In the second method, only

selected data is loaded.

Loading memory data

1 Press the rightmost soft key (next–menu key) on the ALL IO

screen, described in Section III–8.10.1.

2 Press soft key

[M–CARD].

3 Place the CNC in the emergency stop state.

4 When a memory card is inserted, the state of the memory card is

displayed as shown below.

S 0 T0000

EDIT **** - - EMG- - 12: 15: 00

[FORMAT] [ SAVE ] [ LOAD ] [DELETE] [ ]

READ/PUNCH(M–CARD) O1234 N12345

CNC RAM

512K byte 2. 000M byte S- RAM

File ( 1/ 1)

SRAM0_5A. FDB 524288 byte 01/ 01/ 23

Select : All data

Memory card

Message

5 Press soft key [LOAD].

6 With cursor keys

and , select the file to be loaded from the

memory card.

7 To perform selective data loading, press soft key

[SELECT], then

select the data to be loaded. Each time the soft key is pressed, the

information displayed changes cyclically, as shown below.

All data Program Parameter Offset PMC data

C Macro data

8 After checking the file selection, press soft key [EXEC].

9 During loading, the message ”RUNNING” blinks, and the number of

bytes loaded is displayed in the message field.

Loading Data into

Memory (Restoration)

Procedure

EXECCANSELECT
