PROGRAMMING

19. HIGH SPEED CUTTING

FUNCTIONS

B–63614EN/01

376

Item Function

Programmable mirror

image (G51.1)

f(The option of programmable mirror image

is needed.)

Scaling (G51) f(The option of scaling is needed.)

Coordinate system

rotation (G68)

f(The option of coordinate system rotation

is needed.)

Tool compensation f : It is possible to command.

× : It is not possible to command.

Item Function

Cutter compensation C

(G40, G41, G42)

f(The option of cutter compensation C

is needed.)

Tool length compensa-

tion (G43, G44, G49)

Others f : It is possible to command.

× : It is not possible to command.

Item Function

Cycle start / Feed hold f

Dry run f

Single block f

Interlock f

Machine lock f(When the machine lock signal for each axis

(MLK1 A MLK4) is operated, the acceleration /

deceleration of the axis to which the machine

lock is done is ineffective.)

Control in / out ( ) f

Optional block skip (/n) f(The option of optional block skip

is needed.)

MiscellaneousFunction

(Mxxxx)

f(A code signal and a strobe signal are only sent

to the machine.)

Spindle speedFunction

(Sxxxx)

ToolFunction (Txxxx) f(A code signal and a strobe signal are only sent

to the machine.)

Second auxiliaryFunc-

tion (Bxxxx)

f(The option of second auxiliary function

is needed.)

(A code signal and a strobe signal are only sent

to the machine.)

Simple synchronous

control

f(The option of simple synchronous control

is needed.)

(The mode can not be switched.)

Program restart
