5. CONNECTION TO CNC PERIPHERALS
B–63003EN/04
108
(For 160i/180i/210i with an intelligent terminal)
Port name Interface location
First channel on the CNC side
(JD36A)
Main control unit
Second channel on the CNC side
(JD36B)
Main control unit
Third channel on the CNC side
(JD28A)
On the remote buffer option
printed circuit board
First channel on the intelligent
terminal side (JD33)
On the intelligent terminal (*2)
Second channel on the intelligent
terminal side (JD34)
On the intelligent terminal
On the 10.4″ LCD unit or 9.5″
LCD unit for a CNC with a touch
panel
Serial port dedicated to a touch
panel
(*3)
NOTE
1 When a touch panel is used, this serial port is used for touch
panel communication on the CNC side, so that this port
cannot be used as a general–purpose port.
2 When a touch panel is used, this serial port is used for touch
panel communication on the PC side, so that this port
cannot be used as a general–purpose port.
3 This serial port is dedicated to touch panel communication.
Even if no touch panel is attached, this port cannot be used
as a general–purpose port.
