Series 16i/18i/21i/20i/160i/180i/210i/160is/180is/210is - Model A Connection manual (Hardware) Page 19

Connection manual (Hardware)
1. CONFIGURATION
B–63003EN/04
4
Series 16i/18i/21i stand–alone type control units (A circle in the table
denotes that a unit is available.)
The stand–alone type control unit is not available on the Series 20i.
Slot rack name
Expansion
slot
Mini
slot
16i 18i 21i
Re-
marks
Single–slot rack None 2 f f f (*NOTE)
3–slot rack 2 4 f f f (*NOTE)
NOTE
All the stand–alone type control units of the Series
160i/180i/210i are designed to connect an intelligent
terminal by inserting an HSSB interface board into a mini
slot. These control units are the same as those of the Series
16i/18i/21i.
Series 16i/18i/21i display units (A circle in the table denotes that a unit
is available.)
Display
Soft
key
Graphic
display
160i 180i 210i
Re-
marks
10.4″ TFT color LCD 10+2 Provided f f f
10.4″ TFT color LCD
(with touch panel)
None Provided f f f
9.5″ STN
monochrome LCD
10+2 Provided f f f
9.5″ STN
monochrome LCD
10+2 None f f f
Series 160i/180i/210i display units (intelligent terminals) (A circle
denotes that a unit is available.)
Display Soft key 160i 180i 210i Remarks
10.4″ TFT color LCD None f f f
10.4″ TFT color LCD 10+2 f f f
10.4″ TFT color LCD
(with touch panel)
None f f f
1.1.2
Configurations of
Stand–alone Type
Control Units
