Connection manual (Hardware)
9. FANUC INTELLIGENT TERMINAL TYPE 2
B–63003EN/04
198
1 0V 2 DENSEL
30V 4
50V 6
70V 8:INDEX
90V 10:DS0
11 0V 12 :DS1
13 0V 14
15 0V 16 :MT0
17 0V 18 :DIR
19 0V 20 :STEP
21 0V 22 :WDATA
23 0V 24 :WE
25 0V 26 :TRK0
27 0V 28 :WPRT
29 0V 30 :RDATA
31 0V 32 HDSEL
33 0V 34 :DSKCH
1 0V 2 DENSEL
30V 4
50V 6
70V 8:INDEX
90V 10:MT0
11 0V 12 :DS1
13 0V 14 :DS0
15 0V 16 :MT1
17 0V 18 :DIR
19 0V 20 :STEP
21 0V 22 :WDATA
23 0V 24 :WE
25 0V 26 :TRK0
27 0V 28 :WPRT
29 0V 30 :RDATA
31 0V 32 HDSEL
33 0V 34 :DSKCH
Intelligent terminal type 2 Panel–mount type 3.5″ floppy
disk drive
CD34
AMP EI series 4–pin connector
Housing: 171822–4
Contact: 170262 and 170263
1 +12V
20V
30V
4 +5V
1 +5V
20V
3 (NC)
4 (NC)
IDC type FAS–34–17
produced by Yamaichi
Denki
CN2
1 2 3 4
AB
4 3 2 1
J2
NOTE
1 This is a standard interface for the IBM PC compatible. Note the following:
D Only two floppy disk density modes (720 Kbytes and 1.44 Mbytes) are supported.
D The DENSEL signal level is fixed to low.
D Not all commercial floppy disk drives require both +12 V and +5 V power supplies. If your
floppy disk drive requires +12 VDC, pay careful attention to its power requirements.
2 Commercial floppy disk drives are prone to compatibility problems with personal computers to
some degree. It is not guaranteed that the intelligent terminal type 2 can operate with every
commercial floppy disk drive. Machine tool builders are requested to check the operability of
the floppy disk drives they select. Keep in mind that commercial floppy disk drives are neither
dust–proof nor moisture–resistant.
3 The interface on the drive side shown above is only an example. Design an interface cable
according to the specification of the drive with which it is used.
9.7.3
Floppy Disk Drive
(Signal and Power
Supply)
