4. TYPES OF SCREENS
B–62444E–1/04
OPERATION
36
(13) Setting of pre–machining (Processing simulation) (For details, see
II.12.)
Operation guidance for specifying the optimal position at which to
change tools is indicated on this screen. Follow the instructions on
the screen to automatically determine the tool changing position.
PROCESEING SIMULATION *** SETTING OF PRE–MACHING *** [CAP.]
BASIS T–CODE T=
FACE POSITION CZ= 2.000
W–SHIFT SZ=
CHUCK ID NO. C= 1
CHUCK BARRIER X=
Z=
TAILSTOCK NO T=
TOOL–CHG POS X=
Z=
AFTER CHECKING THAT THERE IS NO
INTERFERENCE,PUSH SOFTKEY [ SET ].
RETURN
<
SET TOOLNG
TOOL–CHB
X
(14) Machining simulation screen (For details, see II.7.)
Before the created machining program is executed, it can be checked
with the check drawing screen where the machining operation is
simulated.
1M025
500% STOP *** *** 14:13:15 STOP
00001 P0001
X 69.448
Z –38.850
C 0.000
ACT G01
X 0.000
Z 0.000
C 0.000
NXT G01
X 0.160Z
Z –16.939
C 0.000
WORK
PIECE
<
SPEED
UP
PLOT
ON/OFF
AD PROCES SINGLE
STEP
EXECSPEED
DOWN
+
X
Previous page
Next page
