FANUC SUPER CAP T / CAP II T Operators manual Page 496

Operators manual

Page of 606

/ 606

B–62444E–1/04

R BAR

MACHINING AND PATTERN

REPEATING

EXAMPLES OF CREATING

PROGRAMS

487

EXAMPLE OF INPUTTING CONTOURS FOR BAR

MACHINING AND PATTERN REPEATING

WARNING

The following example of entering contour data is intended

only to illustrate what automatic calculation of intersections is

like when contour data is entered. The contour data given in

the example may not be able to be used in actual machining.

If the machine is forced to run according to a program like the

one shown above, the tool may bump against the workpiece,

and the machine may be forced to perform unnatural

machining, possibly causing damage to the tool and/or

machine, and even injuries.

NOTE

The following examples show the input procedure for

contours, assuming that the process data for bar machining

and pattern repeating has already been input.

R100

φ70

φ32

φ52

Example 1
