Super CAPi-M Data Setting Handbook Operation and maintenance handbook Page 8

Operation and maintenance handbook
1) Display unit: 10.4" LCD
2) ’Super CAP
i
M’ can be used in one path machining
center only
3) Screens are the same as former specification
(up to 16-B/C), Screens for S-CAP
i-
M are new for VGA
4) In case of using PC function, Super CAP
i
M can be used by
CNC screen display function (QQ).
5) Touch panel can be specified only for Super CAP
i
M
6) In case of GEF 160
i
/180
i
/210
i
needs to order CNC Screen
Display Function (A02B-0207-K770)
To make a ’CAP MEM File’, the following items are required:
- Personal Computer
- Memory Card 4 MB
(Please see also ’Order List’)
1. 3 Macro Executer
Following
Development Tools are necessary:
A08B-9001-J501#EN07 MACRO COMPILER for PC
A08B-9001-J800 #ZZ07 Macro Library ’S-CAP iM’ for PC
1. 4 Control System for Super CAPi M
Macro Library ’Super CAPi M’ are the same for following
CNC Series:
16i / 18i / 21i - MA
160i / 180i / 210i-MA
GEF # FL / ecap-con/012000
Configuration GFKE-0041A-EN
- 2 -
