Super CAPi-M Data Setting Handbook Operation and maintenance handbook Page 80

Operation and maintenance handbook
10 DATA BACK - UP
All CAP data can be saved in an external data unit of your
choice. In CAP a special display page is therefore provided.
Beside CAP data the CNC-parameters should also be saved,
because they contain several important CAP settings.
•
CNC-parameter
The CAP data could be in separate files saved, for instance:
•
DEF. FILE
•
PRE TOOL FILE
•
TOOL FILE
•
F.S.- FILE (cutting conditions)
However it is also possible to save all CAP data comprehensi-
vely by selecting
•
All DATA
With the possiblility of storing and restoring all of CAP
data, many variations of tools and cutting condition data
are made available for the customers selection.
CAP Data output/input is possible only by
using RS 232C interface.
DATA I / O
- READ
- PUNCH
- ALL CAP DATA
- DEFAULT DATA
- PRE-TOOL LIST
- TOOL FILE
- F. S. - FILE
READ
EXEC
OR
PUNCH
EXEC
DATA I / O PARAM GUIDE
I / O CHANNEL
I / O DEVICE NO.
= 0
= 0
SELECT FROM SOFT-KEYS
+
FLOPPY
DIR
READ
PRE-
TOOL
TOOL
FILE
F. S.
FILE
PUNCH
ALL
DATA
DEF.
FILE
GEF #FL / escap-06-012000
Data back up GFKE-0041A-EN
- 74 -
Previous page
Next page
