FANUC SERVO AMPLIFIER ßi series I/O Link option Additional Manual Page 36

Additional Manual
A
-77223E/02
図
番
名
称
ペ
｜
ジ
変更内容 設計 年月日
版
FANUC SERVO AMPLIFIER βi series
I/O Link option
DESCRIPTIONS
36 /
NOTE
1 Always install the circuit breakers, magnetic contactor, and AC
line filter.
2 To protect the equipment from lightning surge voltages, install
a lightning surge absorber across each pair of power lines and
across each power line and the grounding line at the power
inlet of the power magnetics cabinet.
WARNING
Defects, such as a loose screw and an incorrectly inserted
connector, can lead to a motor malfunction, excessive heat
generation, and a ground fault. Exercise adequate care in
installing servo amplifiers.
A loose screw (or, if a connector is used, a loose connector
contact or an incorrect connector pin-to-cable connection) on
high-current carrying power supply wires or motor power wires
can lead to fire. Exercise adequate care in wiring.
