FANUC SERVO AMPLIFIER βi series
I/O Link option
DESCRIPTIONS
52 /
5.2.5.3 Power cable for servo motor
A servo motor power cable assembly consists of:
(a) Power cable
(b) Motor-side connector
(a) Power cable
Examples of combining a servo motor and power cable are
described below according to Subsection 5.2.4.2, “Selecting cables
(general).”
[Example combination of servo motor and power cable (reference only)]
Servo motor
Continuous
current rating
[Arms]
(reference only)
[Example 1.]
Cable wire
diameter
[mm
2
]
[Example 2.]
Cable wire
diameter
[mm
2
]
β0.2/5000is
0.84 0.75 0.75
β0.3/5000is
0.84 0.75 0.75
β0.4/5000is
3.5 0.75 0.75
β0.5/5000is
3.0 0.75 0.75
β1/5000is
2.7 0.75 0.75
β2/4000is
3.2 0.75 0.75
β4/4000is
4.7 0.75 0.75
β8/3000is
6.0 0.75 0.75
β12/3000is
10.2 0.75 1.25
β22/2000is
11.3 1.25 1.25
α1/5000i
2.7 0.75 0.75
α2/5000i
3.5 0.75 0.75
α4/4000i
7.7 0.75 0.75
α8/3000i
8.4 0.75 0.75
α12/3000i
18.1 2 3.5
α22/3000i
18.4 2 3.5
α2/5000is
3.3 0.75 0.75
α4/5000is
4.6 0.75 0.75
α8/4000is
11.1 1.25 1.25
α12/4000is
13.4 1.25 2
(b) Motor-side connector
The specifications of a motor-side connector vary depending on the
motor model for which it is used.
Refer to “FANUC AC SERVO MOTOR β
is series Descriptions”
(B-65302EN) for detailed descriptions about motor-side connectors
for the β
is series servo motors.
Refer to “FANUC AC SERVO MOTOR α
is/αi series Descriptions”
(B-65262EN) for detailed descriptions about motor-side connectors
for the αis/αi series servo motors.
