FANUC SERVO AMPLIFIER βi series
I/O Link option
DESCRIPTIONS
66 /
5.2.12.2 List of signals
(1)*+OT ：
Setting the positive overtravel signal input (*+OT) to logical 0
disables forward movement. This signal can be made unusable by
parameter setting.
(2)*-OT ：
Setting the negative overtravel signal input (*-OT) to logical 0
disables reverse movement. This signal can be made unusable by
parameter setting.
(3)*RILK(*DEC)：
Interlock signal input (*RILK) or deceleration signal input for
reference position return (*DEC). One of the two functions is
selected according to parameter setting. If the interlock signal input
(*RILK) is selected, axis motion is decelerated to a stop when this
signal is set to logic 0. When this signal is set to logic 1, axis motion
is resumed. If the deceleration signal input for reference position
return (*DEC) is selected, the feedrate decreases to a certain value
then remains at the decreased value for continued movement when
this signal is set to logic 0. When this signal is set to logic 1, feed
operation stops at an electric grid position.
(4)HDI ：
The rising or falling edge of the skip signal input (HDI) can be used
to cause the current block to be skipped. Whether the rising edge or
falling edge is used depends on the parameter setting.
