Series 15i/150i-Model A Remote Buffer Descriptions Page 26

Descriptions
4. PROTOCOL A B-63322EN-1/01
-20-
Byte
position
Meaning and code
Default value
(hexadecimal)
41 - 44 Unit for the boring time (four digits in
hexadecimal)
Setting parameter P
2
to 1 sets the unit for the
boring time to 0.1 seconds.
0000
45 - 46 Note)
Code to be converted (two-digit hexadecimal
number)
00
47 - 78 Note)
Code after conversion (two-digit hexadecimal
number)
00
49 - 54 Reserve ---
55 - 56 Packet length parameter n of expansion
protocol A (two-digit hexadecimal number)
00: Normal protocol A
01: Expansion protocol A
NC data length = 256 bytes
Packet length = 260 bytes
02: Expansion protocol A
NC data length = 512 bytes
Packet length = 516 bytes
04: Expansion protocol A
NC data length = 1024 bytes
Packet length = 1028 bytes
00
57 - 72 Not used ---
NOTE
Bytes 45, 46, 47, and 48 of SAT
These bytes contain the parameters necessary for the
remote buffer to convert the protocol A <DAT> command
data and expansion protocol A data in the specified
section. Specify the code to be converted in bytes 45
and 46. Specify the code to which conversion is to be
performed in bytes 47 and 48. For details, refer to
Section 4.4.2 (3).
15 0
0000000000000P
00
