  2. Series 15i/150i-Model A Remote Buffer

Series 15i/150i-Model A Remote Buffer Descriptions Page 70

Descriptions
10. PARAMETER B-63322EN-1/01
-64-
5072 RS-422 Number of stop bits (Remote buffer)
[Input type] Setting input
[Data type] Integer
[Valid data range] 1 to 2
Set the number of stop bits of the RS-422 device of the remote buffer.
NOTE
When this stop bit is set to 1, the parity bit is also
provided.
5073 RS-422 baud rate (Remote buffer)
[Input type] Setting input
[Data type] Integer
[Valid data range] 2 to 15
Set the baud rate of the RS-422 device of the remote buffer.
The settings and their corresponding baud rates are as follows.
Setting value baud rate Setting value baud rate
- - 9 2400
2 100 10 4800
3 110 11 9600
4 150 12 19200
5 200 13 38400
6 300 14 76800
7 600 15 86400
8 1200
5074 RS-422 Selection of protocol (Remote buffer)
NOTE
When this parameter is specified, the power must be
turned off and then on again for the parameter settings to
take effect.
[Input type] Setting input
[Data type] Integer
[Valid data range] 1 to 3
1 : Protovol B
2 : Expansion protocol B
3 : Protocol A/expansion protocol A by the
parameter <SET>.
