9. Control & connection/disconnection sequence
・Starting operation with handy machine operator’s panel
Operation ON/OFF switch of handy machine operator’s panel is OFF.
1) The handy machine operator’s panel is connected to the connection panel. (In the case of
detachable connection）
2) The detachable connection switch on the connection panel is turned on. (In the case of detachable
connection)
3) Set the position of the override switch on the handy machine operator’s panel to the present
setting value of override. (Notice 2)
4) Turn on the operation ON/OFF switch on the handy machine operator’s panel.
3) The operation is possible with the handy machine operator’s panel.
・Finishing operation with handy machine operator’s panel
1) Set the state of the alternate switch on the main operator’s panel and touch panel switch to the
state of the switch on the handy machine operator’s panel. (Notice 2)
2) Turn off the operation ON/OFF switch on the handy machine operator’s panel.
3) The detachable connection switch on the connection panel is turned off. (In the case of detachable
connection)
4) The handy machine operator’s panel is removed from the connection panel. (In the case of
detachable connection）
10. Construction parts of handy machine operator’s panel
10.1 Emergency stop button
It is available in all operation modes. This switch has push-lock-turn-reset function and the direct
opening action function. The state of this button can be read by PMC ladder program.
Notice
1. In the case of existing of same purpose switches on the handy machine operator’s panel and
main operator’s panel, and the switch is an alternate switch, there are possibility of damage to
the machine when this sequence is not kept. Example, override is set to 120% with override
switch on the handy machine operator’s panel, but the override switch on the main operator’s
panel is 50%, override is changed from 120% to 50% by turning off the operation ON/OFF
switch.
2. In the case of detachable connection, detachable connection switch must not be turned on with
the state of turning on the operation switch. The override switch and the input key, which is
pushed by accident, are valid after turning on the operation ON/OFF switch.
3. In the case of detachable connection, the Handy machine operator’s panel should not be
connected and disconnected while handle mode. The position of axes may be changed.
4. In the case of detachable connection, the Handy machine operator’s panel should not be
connected when the detachable connection switch on the connection panel is turned on.
Because system alarm may be occurred.
