4.3 Turning LED on/off
By using these output signals, PMC LADDER can control LED.
To turn an LED on/off, turn on/off an output signal corresponds to the LED.
Address Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Y+0 LED2 LED1 (Reserved) LED15 LED14 LED13 LED12 LED11
Y+1 (Reserved) (Reserved) (Reserved) LED25 LED24 LED23 LED22 LED21
Y+2 (Reserved) (Reserved) (Reserved) LED35 LED34 LED33 LED32 LED31
Y+3 (Reserved) (Reserved) (Reserved) LED45 LED44 LED43 LED42 LED41
LED1, LED2, and LED11 to LED45: LED
LED11 to LED45
0 LED lights down
1 LED lights up
When HMOP is viewed from the front, LED array is as follows.
LED 11 LED 12 LED 13 LED 14 LED 15
LED 21 LED 22 LED 23 LED 24 LED 25
LED 31 LED 32 LED 33 LED 34 LED 35
LED 41 LED 42 LED 43 LED 44 LED 45
