Specification, Connection, Maintenance and PMC Programming of Handy machine operators panel Additional Manual Page 34

Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
33
DESCRIPTIONDESIG.DATE
A
-80050E
Bit 4: Valid override switch signal
Bit 4
OVREN
Description
0 OVR0 to 3 signal is invalid
1 OVR0 to 3 signal is valid
4.2.2 Emergency stop button, 3 position enabling switch, Operation on/off switch
ON/OFF state of Operation on/off switch can be read. So, it can be decided that the signals from the
HMOP can be used. And the states of Emergency stop button, 3 position enabling switch and
Operation on/off switch can be confirmed by CNC diagnoses screen.
Address bit7 bit6 Bit5 bit4 bit3 bit2 bit1 Bit0
X+5 (Reserved) (Reserved) (Reserved) OPSW EQDSW DSW2 DSW1 ESP
Bit 0: Emergency stop
Bit0
ESP
Description
0 Emergency stop button is not pushed.
1 Emergency stop button is pushed. Or 24VDC is not supplied to emergency
stop circuit.
Bit 1: Enabling switch (pass1)
Bit1
DSW1
Description
0 Contacts of pass1 of enabling switch or emergency stop button are opened.
Or 24VDC is not supplied to emergency stop circuit.
1 Contacts of pass1 of enabling switch and emergency stop button are closed.
Bit 2: Enabling switch (pass2)
Bit2
DSW2
Description
0 Contacts of pass2 of enabling switch or emergency stop button are opened.
Or 24VDC is not supplied to emergency stop circuit.
1 Contacts of pass2 of enabling switch and emergency stop button are closed.
Bit 3: Comparison of DSW1 and DSW2
Bit3
EQDSW
Description
0 DSW1 and DSW2 are same state （Fusing and attaching of enabling switch
is not occurred.）
1 DSW1 and DSW2 are not same state（Fusing and attaching of enabling
switch is occurred.）
02 2001.8.20 Hanaoka This page is added.
