Assembling the Power Mate H
While assembling your Power Mate H motion system, please observe these guidelines:
1. Always make sure connectors lock into the sockets.
2. The Power Mate H control unit, CRT/MDI unit, Operator's Panel Connection Unit, and I/O
Unit Model A require a regulated 24Vdc power source. This power supply is not provided by
GE Fanuc. When selecting a power source, remember that the Power Mate H requires a 3
amp supply with 24Vdc ± 10%, which includes ripple and noise.
3. Do not overlook the importance of proper grounding for the Power Mate system. Grounding
information is included in this chapter.
4. The Power Mate H has connections on both the face and the bottom of the unit. In general,
connections to motors and external I/O are on the front. Internal I/O and operator interfaces
are connected on the bottom (see Figure 3-1). Before beginning, take time to familiarize
yourself with these connections.
Note
The Power Mate H control should be mounted so that the bottom connections of
the unit are easily accessible.
