Power Mate H Startup Guide Page 63

Startup Guide
6 - 4 Power Mate H Startup Guide - April 1997 GFK-1383A
6
To manually enter your program using the CRT/MDI:
+
INSERTPROG
+
O0001
+
EOB
+
INSERT
+
G91 G94 G00 X600.0 F500.
+
EOB
+
INSERT
+
M30
+
EOB
+
INSERT
+
PROG
To execute a program from memory, switch from EDIT mode to AUTO mode by opening the
Edit mode switch and closing the Auto mode switch. Then, cycle the Cycle Start (ST⇒G007#2)
by pressing your Cycle Start pushbutton (input).
Note
The cycle start input must be turned on and then off in order to execute the command.
Execution starts on the ON to OFF transition of the switch.
To manually enter your program from the MDI/DPL:
PRGRM
+
O0001
+
EOB
+
INSERT
+
INSERT
+
G91
+ +
INSERT
+
G94 G00
+
INSERT
+
INSERT
+
X600.0
++
INSERT
F500.
+
INSERT EOB
+ +
INSERT
+
M30
+
INSERT EOB
+ +
INSERT
To execute a program from memory, switch from EDIT mode to AUTO mode by opening the
Edit mode switch and closing the Auto mode switch. Then, cycle your Cycle Start pushbutton
(input) ON and OFF. The PMC interface bit for Cycle Start is ST⇒G007#2.
