Power Mate H Startup Guide Page 58

Startup Guide
GFK-1383A Chapter 5 Configuring the Power Mate H 5 - 11
5
Table 5-2 Additional Basic Parameters (cont'inued)
Parameter Name Description
1610#0 CTLx Sets ACC/DEC type:
0 = Exponential (also sets 1610#1=1 for bell-shaped ACC/DEC).
1 = Linear.
1610#1 CTBx Sets ACC/DEC type:
0 = Exponential.
1 = Bell-shaped (1610#0 must be set to 0).
1610#4 JGLx Selects ACC/DEC type used for manual jog:
0 = Exponential.
1 = Applies same ACC/DEC type for feed (1610#0,#1).
1620 Sets linear ACC/DEC time in msec for rapid traverse (AUTO mode).
If bell-shaped ACC/DEC is selected (1610#1=1), this parameter specifies the time in
msec for the linear (middle) portion (T1) of the bell-shaped curve (see 1621).
1621 If bell-shaped ACC/DEC is selected (1610#1=1), this parameter specifies the time
constant for corner rounding (T2) at the beginning and end of the ACC/DEC curve.
1622 Sets ACC/DEC time constant for feed (1610#0, 1610#1).
1628 Linear ACC/DEC time for G01 moves.
1825 Servo loop gain. Range is 1 to 9999 (default=3000). (Start with default value. Raise
gain if response is poor. Lower gain if motor buzzing or oscillation occurs.)
1828 Sets following error limit during motion in detection units.
Set=Max Feedrate * 1/60 * 1/Gain * 1/DU * 1.25=Max FDRT * 1/60 * 1/(&1825/100)
* 1/(LCI/CMR) * 1.25.
1829 Sets position error limit when axes are stopped. Valid range is 0 to 32,767. (Set to 500).
1832 Sets feed stop error limit. Axis command automatically stops when servo lag is greater
than value set by this parameter. Disable this function by setting value to 0 (zero).
3003 DI/DO
Enables/disables specific PMC interface bits (see Appendix H of the Power Mate H
Connection Manual, GFZ-62683EN).
3003#5 *DEC Specifies Home (*DEC) switches for home referencing as active low/high.
0 = Home Reference switch is active Low Logic.
(Deceleration starts when this signal is low.)
1 = Home Reference switch is active High Logic.
3005#0 BSKP Enables/disables SKIP function for Built-in I/O only.
0 = Disables SKIP function.
1 = Enables SKIP function.
3005#4 BSKP2 Enables/disables SKIP2 function for Built-in I/O only.
0 = Disables SKIP2 function.
1 = Enables SKIP2 function.
3005#5 BSKP3 Enables/disables SKIP3 function for Built-in I/O only.
0 = Disables SKIP3 function.
1 = Enables SKIP3 function.
3005#7 BSKP4 Enables/disables SKIP4 function for Built-in I/O only.
0 = Disables SKIP4 function.
1 = Enables SKIP4 function.
