Power Mate H Startup Guide Page 42

Startup Guide
3 - 30 Power Mate H Startup Guide - April 1997 GFK-1383A
3
Connecting Machine I/O Using I/O Unit Model A
The addresses for the I/O Unit Model A or other I/O Link devices begin at X0000 for inputs and
Y0000 for outputs. The signal address list is shown in Table 3-6 below. Signals in bold italics
denote dedicated inputs. The "A" suffix denotes signal names used by the standard ladder for
configurations using I/O Unit Model A.
Table 3 - 6. I/O Unit Model A Input and Output Address List
PMC
Address
#7 #6 #5 #4 #3 #2 #1 #0
X0000
SKIP-A *RILKA
ERS-A
*ESP-A
FIN-A
SKIP4A SKIP3A SKIP2A
X0001 ST-A *SP-A KEY-A MLK-A ZRN-A JOG-A AUT-A EDT-A
X0002 PN1-A PN0-A
*DEC6A *DEC5A *DEC4A *DEC3A *DEC2A *DEC1A
X0003 -J4-A +J4-A -J3-A +J3-A -J2-A +J2-A -J1-A +J1-A
Y0000 SPARE SPARE SPARE OP-A MA-A DEN-A AL-AO MF-A
Y0001 SLT-A SPL-A REF-A MMDIA MZRNA MJA MAUTA MEDTA
Y0002 M10-A M09-A M08-A M07-A M06-A M05-A M04-A M03-A
The standard ladder assigns the inputs/outputs to the following rack configuration:
Input Address Group Base Slot Name
X0000 0 0 01 ID16D
X0001 0 0 01 ID16D
X0002 0 0 02 ID16D
X0003 0 0 02 ID16D
Output Address Group Base Slot Name
Y0000 0 0 03 OD08D
Y0001 0 0 04 OD08D
Y0002 0 0 05 OD08D
