Connecting Machine I/O Using a Built-in I/O Card
The addresses for the Built-in I/O card begin at X1000 for inputs and Y1000 for outputs. Signals
in bold italics are dedicated inputs. The "B" suffix denotes signal names used by the standard
ladder for configurations using Built-in I/O card. Terminal numbers reference the appropriate
screw terminal on the externally mounted Screw Terminal Adaptor Board shown in Figure 3-15.
Table 3 - 5. Built-in I/O Card Terminal Block Connections and Address List
Connector CB128 Connector CB129
Screw
Terminal
Number
Address Description
Screw
Terminal
Number
Address Description
1 +24E 24 Vdc Output 1 +24E 24 Vdc Output
2 +24E 24 Vdc Output 2 +24E 24 Vdc Output
3 X1000#0
SKIP2B
3 X1002#0
*DEC1B
4 X1000#1
SKIP3B
4 X1002#1
*DEC2B
5 X1000#2
SKIP4B
5 X1002#2
*DEC3B
6 X1000#3 FIN-B 6 X1002#3
*DEC4B
7 X1000#4
*ESP-B
7 X1002#4
*DEC5B
8 X1000#5 ERS-B 8 X1002#5
*DEC6B
9 DIC Com. for X1000
#0, #1, #2, #7
9 X1002#6 PN0-B
10 X1000#7
SKIP-B
10 X1002#7 PN1-B
11 X1000#6
*RILKB
11 DOC 24 Vdc Input
12 DOC 24 Vdc Input 12 DOC 24 Vdc Input
13 X1001#0 EDT-B 13 X1003#0 +J1-B
14 X1001#1 AUT-B 14 X1003#1 -J1-B
15 X1001#2 JOG-B 15 X1003#2 +J2-B
16 X1001#3 ZRN-B 16 X1003#3 -J2-B
17 X1001#4 MLK-B 17 X1003#4 +J3-B
18 X1001#5 KEY-B 18 X1003#5 -J3-B
19 X1001#6 *SP-B 19 X1003#6 +J4-B
20 X1001#7 ST-B 20 X1003#7 -J4-B
21 Y1000#0 MF-B 21 Y1002#0 M03-B
22 Y1000#1 AL-B 22 Y1002#1 M04-B
23 Y1000#2 DEN-B 23 Y1002#2 M05-B
24 Y1000#3 MA-B 24 Y1002#3 M06-B
(continued)
