Power Mate H Startup Guide Page 51

Startup Guide
5 - 4 Power Mate H Startup Guide - April 1997 GFK-1383A
5
Setting Parameters from the CRT/MDI
Confirm that the operational mode of the Power Mate H is set to Manual Data Input (MDI) or that
the Power Mate H is in the EMERGENCY STOP condition. In MDI mode, the letters MDI will
be displayed in the lower left corner of the screen. MDI is the default mode for the Power Mate H.
In EMERGENCY STOP condition, the letters ESP will be reverse-highlighted. To change
modes, use the Mode Selection switch that you connected during the assembly process (see Figure
3-13). This Mode Selection switch is interfaced via the PMC ladder program or the standard
ladder.
To enter parameter information from the CRT/MDI, you must first enable the parameters to be
changed. This enable is called the Parameter Write Enable (PWE). When set to 1, you may
change parameters. When set to 0, you cannot change the parameters.
Setting the PWE Bit
OFFSET
SETTING
+
SETTING
+
OPRT
+ +
ON:1
When PWE is set to 1, Alarm 100 will appear, indicating that the PWE is enabled. Verify that
the cursor is located on the first line of this SETTING page to set Parameter Write Enable.
Searching for a Parameter
SYSTEM
PARAM
+
desired
parameter
number
+
+
NO. SEARCH
Modifying a Parameter Setting after the Parameter has been Searched
desired value
+
INPUT
