Power Mate H Startup Guide Page 52

Startup Guide
GFK-1383A Chapter 5 Configuring the Power Mate H 5 - 5
5
Resetting the PWE Bit
OFFSET
SETTING
+
SETTING
+
OPRT
+ +
OFF:0
To clear the Alarm 100, EMERGENCY STOP must be cleared and then press
RESET
or cycle power to the Power Mate H.
For more information, refer to the Appendixes in the Power Mate H Connection Manual,
GFZ-62683EN.
Required Parameter Settings
Note
The intent of this publication is to guide you through a process which will allow
you to move an axis. The following information describes the minimum
parameter settings that will accomplish this task. After you have successfully
moved an axis, you should become familiar with all parameters described in
Appendix H of the Power Mate H Connection Manual, GFZ-62683EN. Most
problems you will encounter with the Power Mate H motion system can be
corrected by simply modifying a parameter.
There are four steps that you must perform:
1. Enter values for the parameters described in Table 5-1. Some of these items are on a per-axis
basis, and you must enter values for all axes when you are using a multiple-axis Power Mate
H motion system.
Note
Ignore Alarm 000 (MUST CYCLE POWER) until all parameters in Table 5-1 are
set.
2. Cycle power on the Power Mate H controller.
3. Enter values for the parameters described in Table 5-2.
4. Cycle power on the Power Mate H controller.
