Power Mate H Startup Guide Page 19

Startup Guide
GFK-1383A Chapter 3 Assembling the Power Mate H 3 - 7
3
4. Locate the CRT/MDI power cable GE Fanuc part number 44C741911-004 or FANUC part
number A02B-0124-K830. This cable is connected to the CRT at connector CPD1. The
other end is connected to a regulated 24Vdc power source. The 24V line within the power
cable is connected to the plus (+) terminal, and the 0V line is connected to the minus (–)
terminal (see Figure 3-7).
Note
The CRT/MDI will not work when the DPL/MDI is connected. If the CRT/MDI
unit is to be used, disconnect the DPL/MDI unit.
Connecting the Servo Amplifier to the Power Mate H
To connect the servo amplifier to the Power Mate H:
1. Locate cable 44C742196-00x. Insert one end of this cable into the connector JS1B located on
the bottom of the α Series servo amplifier or on the front of the β Series amplifier (see Figure
3-8).
2. Insert the other end of the cable into the connector labeled AMP1 JS1 on the front of the
Power Mate H.
Note
We recommend that you label connector JS1, along with the axis with which it
corresponds. For example, if this connection is to the X axis, place the letter X on
the connector JS1.
