Power Mate H Startup Guide Page 3

Startup Guide
Preface
GFK-1383A iii
This guide provides a quick, easy way to get the Power Mate H functioning, by leading you step-
by-step through the process, beginning with unpacking the Power Mate H and ending with
generating motion. Along the way, you will become familiar with the Power Mate H control and
associated servos and options.
This guide does not replace any of the existing Power Mate H documentation, but it will help you
become more familiar with the Power Mate H manuals. As you cover the topics in this guide, you
will find a cross-reference to more in-depth or related information in the Power Mate H and servo
manuals.
Note
There are many different combinations of models, motors, servos, and options available
with the Power Mate H. This guide does not attempt to address all of these combinations.
Instead, we have focused on the more popular combinations. Hopefully, it is close to what
you have purchased.
The following Power Mate H configuration was considered when creating this manual:
Component Model Number or Series
Power Mate H XA02B-0211-H501#8880
44A728464-GPM6R00
Built-In I/O Card A02B-0166-K020
9-inch CRT/MDI Terminal Unit A02B-0166-C201#R
AC Servo Amplifiers
α (SVU) or β Series
AC Servo Motors with Built-In Serial Encoder
α (SVU) or β Series
Standard Length Cables from Motion/CNC Express See below
Where applicable, we will also make reference to the following options:
Component Model Number
DPL/MDI Handheld Display Unit A02B-0118-C043
I/O Unit Model A A03B-0807-C001
Series 90-30 I/O Link Module (Slave) IC693BEM320
If you need more information or have any questions during your startup, please contact GE Fanuc
Technical Service Hotline at 1-800-GE FANUC (1-800-433-2682).
