FANUC Series 15i/16i/18i/21i
Remote Diagnostic Function
Host Software (for Windows)
A
-63555EN
Drawing No.
Title
Page
3 1999.7.05 Y.Wakinotani 15i is added T.Ohtsuki
2 1999.3.09 N.Hatanaka Overall revision T.Kurokawa
4.1.2 Pull-down menu
The pull-down menu is shown below.
16i/18i/21i
File Edit Phone Screen Receive Send Others Help
File Print To print the currently displayed screen.
US version > Switching the message language and Screen type
Japanese
version>
eXit Exit the host software
Edit Copy Operations on Diagnose Data Window
Copy to file(I)
select Range
Find
Find Next
Mark
Jump
Select all
Erase diag data
Phone Phone List Operation for connecting CNC via telephone line
Dial
Hang
comm List
Phone history
Screen ( 0) POSITION > To switch CNC screens by selecting menu
( 1) PROGRAM >
( 2) OFFSET >
( 3) SYSTEM >
( 4) MESSAGE >
( 5) CUSTOM >
Previous page
Next page
