FANUC Series 15i/16i/18i/21i
Remote Diagnostic Function
Host Software (for Windows)
A
-63555EN
Drawing No.
Title
Page
3 1999.7.05 Y.Wakinotani 15i is added T.Ohtsuki
2 1999.3.09 N.Hatanaka Overall revision T.Kurokawa
5110 Code number of reader/puncher unit corresponding to device number 1
5120 Code number of reader/puncher unit corresponding to device number 2
5130 Code number of reader/puncher unit corresponding to device number 3
5140 Code number of reader/puncher unit corresponding to device number 4
5150 Code number of reader/puncher unit corresponding to device number 5
5160 Code number of reader/puncher unit corresponding to device number 6
[Input type] Setting input
[Data type] Integer
[Valid data range] 1 - 8
The specification number of the reader/punch device correspoding to device
number 1-6 is set.
The following lists the specification numbers and corresponding reader/punch
device specifications:
Specifi-
cation
No.
Reader/punch device specifications
1 Uses control code (DC1 to DC4). Outputs feeds with punch.
2 Does not use control code (DC1 to DC4). Outputs feeds with
punch.
3 Uses control code (DC1 to DC4). Does not output feeds with
punch.
4 Does not use control code (DC1 to DC4). Does not output feeds
with punch.
5 Portable tape reader
6 PPR, Handy File (local mode)
7 FANUC Cassette (bubble cassette)
8 Floppy Cassette, PROGRAM FILE Mate
Handy File (remote mode)
Set “3” in case Remote Diagnostic function.
