FANUC Series 15i/16i/18i/21i
Remote Diagnostic Function
Host Software (for Windows)
A
-63555EN
Drawing No.
Title
Page
3 1999.7.05 Y.Wakinotani 15i is added T.Ohtsuki
2 1999.3.09 N.Hatanaka Overall revision T.Kurokawa
5001 Device number of reader/puncher unit connected to JD5A of MAIN
[Input type] Setting input
[Data type] Integer
[Valid data range] 1 - 6
Set the device number of the reader/puncher unit connected to connector JD5A.
And, set the code numbers of the reader/puncher units corresponding to device
numbers 1 to 6 in parameter No. 5100 to 5162.
5002 Device number of reader/puncher unit connected to JD5B of MAIN
[Input type] Setting input
[Data type] Integer
[Valid data range] 1 - 6
Set the device number of the reader/puncher unit connected to connector JD5B.
And, set the code numbers of the reader/puncher units corresponding to device
numbers 1 to 6 in parameter No. 5100 to 5162.
5003 Device number of reader/puncher unit
connected to JD36A of the display unit
[Input type] Setting input
[Data type] Integer
[Valid data range] 1 - 6
Set the device number of the reader/puncher unit connected to connector JD36A.
And, set the code numbers of the reader/puncher units corresponding to device
numbers 1 to 6 in parameter No. 5100 to 5162.
5004 Device number of reader/puncher unit connected to modem card
[Input type] Setting input
[Data type] Integer
[Valid data range] 1 - 6
Set the device number of the reader/puncher unit connected to modem card.
And, set the code numbers of the reader/puncher units corresponding to device
numbers 1 to 6 in parameter No. 5100 to 5162.
