FANUC Series 15i/16i/18i/21i
Remote Diagnostic Function
Host Software (for Windows)
A
-63555EN
Drawing No.
Title
Page
3 1999.7.05 Y.Wakinotani 15i is added T.Ohtsuki
2 1999.3.09 N.Hatanaka Overall revision T.Kurokawa
0204 Channel used for remote diagnosis
[Data type] Byte
[Valid data range] 0, 1, 2
Interface used for remote diagnosis
0, 1 : RS-232-C Serial Port 1 (Channel 1)
2 : RS-232-C Serial Port 2 (Channel 2)
0211 Password 1 for remote diagnose
0212 Password 2 for remote diagnose
0213 Password 3 for remote diagnose
[Valid data range] 1 - 99999999
These parameters set passwords for using the remote diagnosis function.
With the remote diagnosis function, three types of passwords are available for
protecting data. These passwords help to prevent unauthorized persons from
accessing system parameters and machining programs.
Password 1:
Sets a password for all services of the remote diagnosis function.
(No remote diagnosis function services are available until this password is
entered on the host computer (personal or other)).
Password 2:
Sets a password for part programs.
(Program-related operations such as program data input/output and check
cannot be performed until this password is entered on the host computer
(personal or other)).
Password 3:
Sets a password for parameters.
(Parameter-related operations such as parameter data input/output and cannot
be performed until this password is entered on the host computer (personal or
other)).
NOTE
Once a value other than 0 is set as a password, the password
cannot be modified until the same value is set in the
corresponding keyword parameter (parameter No. 221 to 223).
When a value other than 0 is set as a password, only blanks are
displayed. Care must be taken in setting a password.
