OPEN CNC (DNC Operation Management Package) Operators manual Page 96

Operators manual
6. CUSTOMIZATION B-63214EN/01
- 80 -
13. Click the <OK> button on the [Edit Screen Object] screen.
A screen object is created.
NOTE
l When "EXE file" is selected for the object type, this item need
not be set.
l The background color can be changed only for those screen
objects that have the BackColor property. Currently, not all
CNC screens have the BackColor property. (Determine
whether the specified screen object has the BackColor
property by using the Visual Basic property window or by
some other method.)
l When &HFFFFFFFF is specified for the background color, the
default background color is set.
