Handy Machine Operator Supplement to Manual Page 110

Supplement to Manual
A.CONNECTING A MANUAL PULSE GENERATOR FOR 16i/18i/21i-A/B, AND Power Mate i APPENDIX B-63753EN/01
- 102 -
In the example illustrated above, the manual pulse generators
connected to groups #0, #1, and #2 are enabled, and the manual
pulse generator connected to the handy machine operator's panel
of group #3 cannot be used.
2. New method (This method can be used with Power Mate i-D/H
only.)
Any X addresses to which manual pulse generators can be
connected can be used.
The manual pulse generators connected to any groups specified
by parameters can be used.
Parameter
Power Mate i-D/H
#7 #6 #5 #4 #3 #2 #1 #1
7105 HXS
HXS The manual pulse generators are allocated to I/O Link by:
0 : The conventional method.
Up to three manual pulse generators related to smallest group
numbers used for the connection of I/O Link can be used
automatically.
1 : The new method. (Parameters 7120 to 7122 are referenced.)
Up to three manual pulse generators related to specified group
numbers can be used, irrespective of the order of connection.
7120 X address to which the first manual pulse generator is allocated
7121 X address to which the second manual pulse generator is allocated
7122 X address to which the third manual pulse generator is allocated
[Data type] Byte
[Valid data range] 0 to 128
NOTE
If an address to which a manual pulse generator
cannot be allocated is specified in the parameter,
the change in the value is ignored, resulting in no
axial operation.
