Handy Machine Operator Supplement to Manual Page 39

Supplement to Manual
B-63753EN/01 SPECIFICATION 11.FANUC STANDARD KEY SHEET A
- 31 -
• When the “RESET” key is pushed, CNC is reset.
Reset and rewind signal should be on for rewinding part
program.
• Override can be applied to feedrate speed by the override
switch on handy machine operator’s panel. Set feedrate
override signal from 0% to 120% according to the override
switch position.
• When the “×n” key is pushed, rapid traverse override is
applied. Please rotate the setting value 100%→50%→
25%→F0→100% by each pushing this key.
• For test operation, Dry run “DRY RUN” and single block
“SINGLE BLOCK” are available.
• One axis position is displayed normally. When the “XYZ
456” key is pushed, next axis position is displayed.
<Display example>
Program number Block number Present rapid override
O1000 N0010 100%
X-99999
.
999 120%
Position display Present feedrate override
2) Manual handle feed
The keys to use are shaded in the following figure.
XYZ
456
REF
SPINDL
START
SPINDL
STOP
RESET
HANDLE JOG
SPINDL
INC
SPINDL
DEC
+
×n MEM
FUNC
TION
MESSAG RAPID
SINGLE
BLOCK
DRY
RUN
CYCLE
START
FEED
HOLD
-
• When the “HANDLE” key is pushed, mode is changed to
manual handle feed mode.
• The axis, which is moved by MPG, is selected by pushing
the “XYZ 456” key several times. And the selected axis is
decided for pushing the “FUNCTION” key.
• When “×n” key is pushed, manual handle feed amount
selection is applied. Please rotate ×1→×10→×m→×n by
each pushing of this key.
• When the “RESET” key is pushed, the moving axis is
stopped.
<Display example>
Spindle speed
S-20000
X-99999
.
999 *127
Position display manual handle feed amount selection
