Handy Machine Operator Supplement to Manual Page 43

Supplement to Manual
B-63753EN/01 SPECIFICATION 13.SUPPLEMENT
- 35 -
13 SUPPLEMENT
1) The following edition number or later of control software of
CNC is necessary for Handy machine operator’s panel.
16i-TA 18i-TA 21i-TA 16i-MA 18i-MA
Edition 01 of
B1F4
Edition 01 of
BEF4
Edition 01 of
DEF4
Edition 02 of
B0F4 02
Edition 02 of
BDF4
21i-MA 16i-TB 18i-TB 21i-TB 16i-MB
Edition 02 of
DDF4 02
Edition 03 of
B1H1
Edition 03 of
BEH1
Edition 03 of
DEH1
Edition 02 of
B0H1
18i-MB 21i-MB 15i-MA 15i-MA PM i-D
Edition 02 of
BDH1
Edition 02 of
DDH1
Edition 01 of
F008
Edition 01 of
F608
Edition 15 of
88E0
PM i-H
Edition 07 of
88F1
2) The following edition number or later of control software of
PMC is necessary for Handy machine operator’s panel.
PMC-SB5/SB6 PMC-SA1 PMC-SB7 PMC-NB6
Edition 18 of 406A or
Edition 01 of 406H
Edition 01 of
406G
Edition 01 of
404A
Edition 02 of
406A
Edition 09 of
407B
3) When the time of one period of PMC ladder program is very
long, key input is not accepted. The time of one period of PMC
ladder program must be the time that key input is accepted
certainly. The standard time is about 50ms.
4) The display routine of LCD should be run periodically. The
standard time is about 200ms. Especially for position display, the
changing of position is not smooth when the periodic time is
exceeding the standard time.
5) When two input keys are pushed at the same time, PMC ladder
program can read these input keys. But when three or more input
keys are pushed at the same time, PMC ladder program can not
read these input keys.
6) In the case of connecting a HMOP to FANUC I/O Link, that
MPGs have been connected already, please refer to appendix A
(for 16i/18i/21i-A/B and Power Mate i) . This method is possible
with 15i from before.
7) In the case of 16i/18i/21i-A/B which are correspond to FANUC
I/O Link 2 channels, please refer to appendix B for the
connecting HNOP to channel No. 2 of FANUC I/O Link.
(The Series 15i and Power Mate i do not have the second
channel of I/O Link.)
