Handy Machine Operator Supplement to Manual Page 27

Supplement to Manual
B-63753EN/01 SPECIFICATION 9.CONTROL & CONNECTION/ DISCONNECTION SEQUENCE
- 19 -
CAUTION
1 In the case of existing of same purpose switches on
the handy machine operator’s panel and main
operator’s panel, and the switch is an alternate
switch, there are possibility of damage to the
machine when this sequence is not kept. Example,
override is set to 120% with override switch on the
handy machine operator’s panel, but the override
switch on the main operator’s panel is 50%,
override is changed from 120% to 50% by turning
off the operation ON/OFF switch.
2 In the case of detachable connection, detachable
connection switch must not be turned on with the
state of turning on the operation switch. The
override switch and the input key, which is pushed
by accident, are valid after turning on the operation
ON/OFF switch.
3 In the case of detachable connection, the Handy
machine operator’s panel should not be connected
and disconnected while handle mode. The position
of axes may be changed.
4 In the case of detachable connection, the Handy
machine operator’s panel should not be connected
when the detachable connection switch on the
connection panel is turned on. Because system
alarm may be occurred.
