Handy Machine Operator Supplement to Manual Page 41

Supplement to Manual
B-63753EN/01 SPECIFICATION 11.FANUC STANDARD KEY SHEET A
- 33 -
5) Spindle control
The keys to use are shaded in the following figure.
XYZ
456
REF
SPINDL
START
SPINDL
STOP
RESET
HANDLE JOG
SPINDL
INC
SPINDL
DEC
+
×nMEM
FUNC
TION
MESSAG RAPID
SINGLE
BLOCK
DRY
RUN
CYCLE
START
FEED
HOLD
-
• When the “SPINDL START ” key is pushed, spindle motor
is rotated to the direction, which is designed, with the speed
at the decided override.
• When the “SPINDL STOP ” key is pushed, spindle motor is
stopped.
• When the “SPINDL INC” key or the “SPINDL DEC” key is
pushed, override of spindle speed is changed. The changing
rate is decided by PMC ladder program.
6) User define key [FUNCTION]
We recommend that this key should be used for confirmation of
axis selection in manual handle feed mode, manual continuous
feed mode and manual reference position return. The position
display should be space and the axis name should be turned on
and off until pushing the confirmation key. When selected axis is
changed by miss-operation, it is danger because different axis,
which is not paid attention, is moved.
When user thinks that the confirmation of axis selection is not
necessary or other mode, user can apply this key to other purpose
at his own risk. (Example, this key may be used for clamp
/unclamp at loader and coolant on/off at machining center.)
7) Message key [MESSAG]
When the “MESSAG” key is pushed, the screen is changed to
user message screen. The next message screen is displayed after
another pushing the “MESSAG” key. When the “XYZ 456” key
is pushed, the screen is returned to the screen according to each
mode.
