AC SERVO MOTOR Alpha series Descriptions Page 103

Descriptions
B–65142E/04
8. CONNECTORSDESCRIPTIONS FOR α series
87
The FANUC α series AC servo motors use TÜV–approved connectors
on the power cable and brake/fan unit in order to comply with the IEC34
standard. Dripproof receptacle connectors are used as standard for all
cables including those for signals (except for the α1, and α2 series).
These connectors are dripproof even when not engaged.
Strictly speaking, the IEC34 for connectors is different from the MS
standard with respect to the connector disengaged–state waterproof
function and appearance (black in color). However, the TÜV–approved
connectors are compatible with the MS–standard round connectors in size
and shape. So, MS–standard plug connectors other than those
recommended below are also usable. (The waterproof plug connectors
recommended in Sections 8.3.1 and 8.3.2 should be used if it is necessary
to keep the whole system waterproof.)
Connectors for α1 and α2
Motor Type For Power For Signal For Brake
α1/3000
α2/2000, α2/3000
αM2/3000
αM2.5/3000
176339–2
(AMP Japan)
SDAB–15P
(Hirose Electric)
Power connectors are used. For
details, see chapter “7. Brakes.”
8.1
CONNECTOR ON
THE MOTOR SIDE
8.1.1
Specifications of
Connectors on the
Motor Side
